Replacing the Logo Board
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before Working Inside Your Computer.
After working inside your computer, follow the instructions
in After Working Inside Your Computer. For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the logo board to the screw holes on the bracket
and slide the logo board in.
2 Replace the screws that secure the logo board to the bracket.
3 Slide the logo board inside the chassis.
4 Replace the screw that secure the logo board to the bracket.
5 Route and connect the cables that you removed from the connectors on
the logo board.
Post-requisites
1 Replace both the left and right side-panels. See “Replacing the Side
Panels”.
2 Replace the stability foot.
116
