Removing the Right AlienFX
Side-Panel Connector
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before Working Inside Your Computer.
After working inside your computer, follow the instructions
in After Working Inside Your Computer. For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Prerequisites
1 Remove the stability foot.
2 Remove both the left and right side-panels. See “Removing the Side
Panels”.
Procedure
1 Lay the chassis on the left side.
2 Disconnect the cable that connects the right AlienFX side-panel connector
to the I/O board. See “I/O Board Components”.
3 Remove the screw that secures the right AlienFX side-panel connector
assembly to the chassis.
