Alienware Area-51 R2 - Removing the Drive-Bay Heat-Sensor; Prerequisites; Procedure

Removing the Drive-Bay
Heat-Sensor
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before Working Inside Your Computer.
After working inside your computer, follow the instructions
in After Working Inside Your Computer. For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Prerequisites
1 Remove the stability foot.
2 Remove both the left and right side-panels. See “Removing the Side
Panels”.
Procedure
1 Lay the chassis on the left side.
2 Locate the drive-bay heat-sensor connector (SENSOR1) on the system
board. For more information on the drive-bay heat-sensor connector, see
“
System-Board Components”.
58
