Replacing the Left AlienFX
Side-Panel Connector
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before Working Inside Your Computer.
After working inside your computer, follow the instructions
in After Working Inside Your Computer. For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
1 Replace the screws that secure the left AlienFX side-panel connector to the
bracket.
2 Replace the screws that secure the left AlienFX side-panel connector to the
chassis.
3 Connect the cable that connects the left AlienFX side-panel connector to
the system board.
Post-requisites
1 Replace both the left and right side-panels. See “Replacing the Side
Panels”.
2 Replace the stability foot.
