Right View
1 processor liquid-cooling
assembly-fan
2 graphics card
3 system board 4 power-supply
5 AlienFX side-panel connector 6 PCI fan
7 processor liquid-cooling assembly
pump
8 memory modules
9 memory fan (top fan)
