Replacing the Battery Case
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before Working Inside Your Computer.
After working inside your computer, follow the instructions
in After Working Inside Your Computer. For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
1 Align the screw holes on the battery-case with the screw holes on the
chassis.
2 Replace the screws that secure the battery-case to the chassis.
3 Connect the battery-case cable to the chassis.
4 Insert the batteries and close the battery-compartment door.
Post-requisites
1 Replace the right side-panel. See “Replacing the Side Panels”.
2 Replace the stability foot.
