Replacing the Front-bezel
Heat-sensor
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in
Before Working Inside Your Computer.
After working inside your computer, follow the instructions
in After Working Inside Your Computer. For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
1 Reroute the chassis heat-sensor in the bracket.
2 Align the chassis heat-sensor in the securing clip.
3 Close and press the release tab on the securing clip.
Post-requisites
1 Replace the PCI fan.
2 Replace both the left and right side-panels. See “Replacing the Side
Panels”.
3 Replace the stability foot.
88
