2. Remove the left-side cover.
3. Remove the top cover.
4. Remove the right-side cover.
5. Remove the front bezel.
6. Remove the
memory modules.
7. Remove the single-graphics card.
8. Remove the 2230 solid-state drive or the 2280 solid-state drive in SSD slot one, as applicable.
9. Remove the
2230 solid-state drive or the 2280 solid-state drive in SSD slot two, as applicable.
10.Remove the wireless card.
11. Remove the processor liquid-cooling assembly or processor fan and heat-sink assembly, as applicable.
12. Remove the processor.
13. Remove the VR heat sink.
About this task
The following image indicates the connectors on your system board.
82
