Alienware AW3225QF User Manual

About your monitor | 23
Pin assignments
DisplayPort connector
Pin number 20-pin side of the connected signal cable
1ML3 (n)
2GND
3ML3 (p)
4ML2 (n)
5GND
6ML2 (p)
7ML1 (n)
8GND
9ML1 (p)
10 ML0 (n)
11 GND
12 ML0 (p)
13 GND
14 GND
15 AUX (p)
16 GND
17 AUX (n)
18 Hot Plug Detect
19 Re-PWR
20 +3.3 V DP_PWR

Alienware AW3225QF Specifications

General

Resolution	3840 x 2160 (4K UHD)
Panel Type	QD-OLED
Refresh Rate	240 Hz
Aspect Ratio	16:9
Color Gamut	99% DCI-P3
Speakers	No
Response Time	0.03 ms (Gray-to-Gray Min)
Brightness	1000 nits (peak)
HDR	VESA DisplayHDR True Black 400
Viewing Angle	178° (H) / 178° (V)
Connectivity	2x HDMI 2.1, 1x DisplayPort 1.4
USB Hub	Yes (USB 3.2 Gen 1)
Adjustability	Height, tilt
Adaptive Sync	Yes, NVIDIA G-SYNC Compatible
