26 | About your monitor
Universal Serial Bus (USB) interface
This section provides information about the
USB ports that are available on the
monitor.
Transfer speed Data rate Power consumption*
Super-Speed 5 Gbps 4.50 W (maximum each port)
High speed 480 Mbps 4.50 W (maximum each port)
Full speed 12 Mbps 4.50 W (maximum each port)
NOTE: This monitor is SuperSpeed USB 5 Gbps (USB 3.2 Gen 1)
compatible.
Super speed USB 5 Gbps (USB 3.2 Gen 1)
USB Type-C Description
Data SuperSpeed USB 5 Gbps (USB 3.2 Gen 1)
Power charging Up to 15 W
USB Type-C
*Up to 3 A on USB-C downstream port (with
battery icon) with battery
charging version-compliant devi
ces or normal USB devices.
USB 3.2 Gen 1 (5 Gbps) upstream connector
Pin number Signal name
1VBUS
2D-
3D+
4GND
5StdB_SSTX-
6StdB_SSTX+
7GND_DRAIN
