34 | Setting up the monitor
Setting up the monitor
Attaching the stand
NOTE: The stand assembly is not pre-installed when the monitor is
shipped from the factory.
NOTE: The following instructions are applicable only for the stand that
was shipped with your monitor. If you are attaching a stand that you
purchased from any other source, follow the setup instructions that are
included with the stand.
CAUTION: The following steps are important to protect you
r screen.
Follow the instructions to complete the installation.
1. Remove the stand riser, stand base, a
nd I/O cover from the packaging
cushion.
NOTE: The images are for the purpose of illustration only. The
appearance of the package cushion may vary.
2. Al
ign and place the stand riser on the stand base.
3. O
pen the screw handle at the bottom of the stand base and turn it
clockwise to secure the stand assembly.
4. C
lose the screw handle.
