KINTEX UltraScale+ FPGA Board AXKU040 User Manual
SFP1 Data Receiver (Positive)
SFP1 Data Receiver (Negative)
SFP1 Optical Transfer Disable, active high
SFP1 Optical LOSS,High level means no
light signal is received
The 2
nd
fiber interface FPGA pin assignment is as follows:
SFP2 Data Transmission (Positive)
SFP2 Data Transmission (Negative)
SFP2 Data Receiver (Positive)
SFP2 Data Receiver (Negative)
SFP2Optical Transfer Disable, active high
SFP2 Optical LOSS,High level means no
light signal is received
The 3
rd
fiber interface FPGA pin assignment is as follows:
SFP3 Data Transmission (Positive)
SFP3 Data Transmission (Negative)
SFP3 Data Receiver (Positive)
SFP3 Data Receiver (Negative)
SFP3 Optical Transfer Disable, active high
SFP3 Optical LOSS,High level means no
light signal is received
The 4
th
fiber interface FPGA pin assignment is as follows:
SFP4 Data Transmission (Positive)
SFP4 Data Transmission (Negative)
SFP4 Data Receiver (Positive)
SFP4 Data Receiver (Negative)
SFP4 Optical Transfer Disable, active
high
SFP4 Optical LOSS,High level means no
light signal is received
To Next Page
