HDMI_D0
IO_L20N_T3L_N3_AD1N_48
Y30
HDMI Video Signal Data 0
HDMI_D1
IO_L19N_T3L_N1_DBC_AD9N_48
Y33
HDMI Video Signal Data 1
HDMI_D2
IO_L22N_T3U_N7_DBC_AD0N_48
Y32
HDMI Video Signal Data 2
HDMI_D3
IO_L19P_T3L_N0_DBC_AD9P_48
W33
HDMI Video Signal Data 3
HDMI_D4
IO_L21N_T3L_N5_AD8N_48
W34
HDMI Video Signal Data 4
HDMI_D5
IO_L24N_T3U_N11_48
W31
HDMI Video Signal Data 5
HDMI_D6
IO_L22P_T3U_N6_DBC_AD0P_48
Y31
HDMI Video Signal Data 6
HDMI_D7
IO_L23N_T3U_N9_48
V34
HDMI Video Signal Data 7
HDMI_D8
IO_T3U_N12_48
V32
HDMI Video Signal Data 8
HDMI_D9
IO_L23P_T3U_N8_48
U34
HDMI Video Signal Data 9
HDMI_D10
IO_L24P_T3U_N10_48
V31
HDMI Video Signal Data 10
HDMI_D11
IO_L20P_T3L_N2_AD1P_48
W30
HDMI Video Signal Data 11
HDMI_D12
IO_L23N_T3U_N9_47
W29
HDMI Video Signal Data 12
HDMI_D13
IO_L23P_T3U_N8_47
V29
HDMI Video Signal Data 13
HDMI_D14
IO_L21P_T3L_N4_AD8P_47
W28
HDMI Video Signal Data 14
HDMI_D15
IO_L19N_T3L_N1_DBC_AD9N_47
V28
HDMI Video Signal Data 15
HDMI_D16
IO_L19P_T3L_N0_DBC_AD9P_47
V27
HDMI Video Signal Data 16
HDMI_D17
IO_L24N_T3U_N11_47
W26
HDMI Video Signal Data 17
HDMI_D18
IO_L24P_T3U_N10_47
V26
HDMI Video Signal Data 18
HDMI_D19
IO_L22N_T3U_N7_DBC_AD0N_47
U27
HDMI Video Signal Data 19
HDMI_D20
IO_L22P_T3U_N6_DBC_AD0P_47
U26
HDMI Video Signal Data 20
HDMI_D21
IO_L20N_T3L_N3_AD1N_47
U25
HDMI Video Signal Data 21
HDMI_D22
IO_L20P_T3L_N2_AD1P_47
U24
HDMI Video Signal Data 22
HDMI_D23
IO_T1U_N12_47
Y22
HDMI Video Signal Data 23
HDMI_SCL
IO_L21N_T3L_N5_AD8N_D07_65
R22
HDMI IIC Control Clock
HDMI _SDA
IO_L21P_T3L_N4_AD8P_D06_65
R21
HDMI IIC Control Data
