SD Card Slot pin assignment:
Signal
Name
FPGA Pin
FPGA Pin
Number
Description
SD_CLK
IO_L22P_T3U_N6_DBC_AD0P_64
AN8
SD Clock Signal
SD_CMD
IO_L21N_T3L_N5_AD8N_64
AL9
SD Command Signal
SD_D0
IO_L24N_T3U_N11_64
AL8
SDData0
SD_D1
IO_L22N_T3U_N7_DBC_AD0N_64
AP8
SDData1
SD_D2
IO_L23P_T3U_N8_64
AJ9
SDData2
SD_D3
IO_L21P_T3L_N4_AD8P_64
AK10
SDData3
SD_CD
IO_L23N_T3U_N9_64
AJ8
SD card insertion signal
