related parameters of eMMC FLASH are shown in Table 2-5-1.
Table 2-5-1: eMMC FLASH Specification
The eMMC FLASH is connected to the GPIO port of the BANK500 of the
PS part of the ZYNQ UltraScale+. In the system design, it is necessary to
configure the GPIO port function of the PS side as an EMMC interface. Figure
2-5-1 shows the part of eMMC Flash in the schematic diagram.
Figure 2-5-1: QSPI Flash in the schematic
Configuration Chip pin assignment:
