Chapter
3
Installing the Module
Chapter Objectives
Chapter 3 provides the information that you need to install the
module (1203-GD1 module, 1203-GK1 module, or 1336-GM1
board). In this chapter, you will read about the following:
• Selecting cables.
• Selecting a termination resistor.
• Installing a 1203-GD1 or 1203-GK1 module.
• Installing a 1336-GM1 board.
Selecting Cables
Refer to the following table to determine the required cables:
SCANport Cables
When selecting the SCANport cable to connect a module to the
SCANport product, you need to:
• Use an Allen-Bradley SCANport cable. Refer to the table below:
• Use 10 meters (33 feet) or less of cable between the SCANport
product and all peripherals.
• Keep SCANport cables away from high power cables to guard
against introducing noise into your system.
Important:
SCANport cables lock into a connection. To remove a
SCANport cable, you must push it in and then pull it out.
If Installing: Required Cables
1203-GD1, 1203-GK1 SCANport and Remote I/O
1336-GM1 Remote I/O
Male to Male Connection Male to Female Connection
➀
Length Catalog Number Length Catalog Number
1/3 m 1202-C03 1/3 m 1202-H03
1 m 1202-C10 1 m 1202-H10
3 m 1202-C30 3 m 1202-H30
9 m 1202-C90 9 m 1202-H90
➀
Cables with male to female connections are generally used as extension cables.
