Allen-Bradley 1203 Series User Manual

A–2 Specifications
1203-GD1 Module
Specifications
The following table gives the specifications for the 1203-GD1
module.
1203-GK1 Module
Specifications
The following table gives the specifications for the 1203-GK1
module.
Category Specifications
Electrical Input Voltage
Input Current
Input Frequency
SCANport Load
85 to 264 V AC, 1 phase
35 mA maximum
45 to 63 Hz
60mA DC
Environmental Operating Temperature
Storage Temperature
Relative Humidity
0 to +50
°
C (32 to 122
°
F)
–40 to +85
°
C (–40 to 185
°
F)
0 – 95%, non-condensing
Communications Product
Controller
Baud Rates
Rack Sizes
SCANport
Allen-Bradley Remote I/O
57.6K, 115.2K, 230.4K
1/4, 1/2, 3/4, full
Mechanical Height
Width
Depth
Enclosure
DIN Rail Standard
76 mm (3.0")
45 mm (1.8")
123 mm (4.8")
NEMA Type 1 (IP30)
35 x 7.5 mm (1.38 x 0.30 in)
Regulatory
Agencies
UL
CSA
CE
Category Specifications
Electrical Input Voltage
Input Current
SCANport Load
24 V DC, +/- 10%
0.4 A maximum
60mA DC
Environmental Operating Temperature
Storage Temperature
Relative Humidity
0 to +50
°
C (32 to 122
°
F)
–40 to +85
°
C (–40 to 185
°
F)
0 – 95%, non-condensing
Communications Product
Controller
Baud Rates
Rack Sizes
SCANport
Allen-Bradley Remote I/O
57.6K, 115.2K, 230.4K
1/4, 1/2, 3/4, full
Mechanical Height
Width
Depth
Enclosure
DIN Rail Standard
76 mm (3.0")
45 mm (1.8")
123 mm (4.8")
NEMA Type 1 (IP30)
35 x 7.5 mm (1.38 x 0.30 in)
Regulatory
Agencies
UL
CSA
CE
