Allen-Bradley 1305 Series User Manual

Troubleshooting and Fault Information
6-7
Table 6.B 1305 Fault Descriptions
(continued)
Fault Name & Number Fault Description Action to Take
Pin ID Error Communication Hardware problem. 1. Unplug the HIM from the cable or drive and re-connect.
2. Replace Communication Cable.
Power Loss Fault
F3
DC bus voltage remained below 85% of nominal for longer than
0.500 sec. [Line Loss Fault] parameter is programmed to “F03
Enable”.
Monitor the incoming AC line for low voltage or line power
interruption.
Power Mode Fault
F26
Internal error. Reset drive to factory defaults.
Power Test Fault
F46
Fault detected during initial start-up sequence. Check drive wiring. Check motor wiring. Reset drive to factory
defaults.
Reprogram Fault
F48
Occurs when drive parameters are reset to defaults. Clear fault.
Run Boost Fault
F34
An attempt has been made to set the [Run Boost] parameter to
a value greater than the [Start Boost] parameter.
Verify that parameter has been programmed correctly.
Serial Fault An active local bus adapter is disconnected while it possesses Check for break in communications line.
Serial
Fault
F10
An
active
local
bus
adapter
is
disconnected
while
it
possesses
control of a local bus function.
Check
for
break
in
communications
line.
