Installation/Wiring
Chapter
2
CHAPTER OBJECTIVES
Chapter 2 provides the information needed to properly mount
and wire the drive. Since most start-up difficulties are the
result of incorrect wiring, every precaution must be taken to
assure that the wiring is done as instructed. All items must be
read and understood before the actual installation begins.
ATTENTION: The following information is
merely a guide for proper installation. The National
Electrical Code and any other governing regional
or local code will overrule this information. The
Allen-Bradley Company cannot assume
responsibility for the compliance or the
noncompliance to any code, national, local or
otherwise for the proper installation of this drive or
associated equipment. A hazard of personal injury
and/or equipment damage exists if codes are
ignored during installation.
!
Figure 2.1 Mounting Requirements
JOG
ESC SEL
JOG
ESC SEL
76.2 mm
(3.0 in.)
50.8 mm
(2.0 in.)
50.8 mm
(2.0 in.)
Important: The drive must be mounted to a metallic surface.
