Allen-Bradley 1305 Series User Manual

Installation/Wiring
2-2
Figure 2.2 Bulletin 1305 Approximate Dimensions
Dimensions shown are in millimeters (inches). Shipping weights are in kilograms (pounds).
A
B
C
D
E
FG
H
J
C’
O 22.5
(7/8)
O 5.5
(7/32)
200/230 V
Cat. No.
1305- . . .
380/460 V
Cat. No.
1305- . . .
A
Width
B
Height
C
Depth
w/o Pot.
C’
Depth
w/ Pot.
D E F G H J
Approx.
Shipping
Weight
AA02A
AA03A
120
(4-23/32)
195
(7-11/16)
122
(4-13/16)
127.1
(5)
110
(4-11/32)
180
(7-1/16)
9
(11/32)
113
(4-7/16)
5
(7/32)
7.5
(5/16)
1.6
(3.5)
AA04A 120
(4-23/32)
195
(7-11/16)
140
(5-1/2)
145.1
(5-23/32)
110
(4-11/32)
180
(7-1/16)
27
(1-1/16)
113
(4-7/16)
5
(7/32)
7.5
(5/16)
1.9
(4.2)
AA08A BA01A
BA02A
BA03A
BA04A
BA06A
170
(6-11/16)
195
(7-11/16)
179
(7-1/16)
184.1
(7-1/4)
160
(6-5/16)
180
(7-1/16)
66
(2-19/32)
113
(4-7/16)
5
(7/32)
7.5
(5/16)
3.6
(8.0)
AA12A BA09A 210
(8-1/4)
195
(7-11/16)
179
(7-1/16)
184.1
(7-1/4)
200
(7-7/8)
180
(7-1/16)
66
(2-19/32)
113
(4-7/16)
5
(7/32)
7.5
(5/16)
4.2
(9.2)
