Allen-Bradley 1305 Series - Process Display; Process Par; Process Scale; Process Txt

Programming
5-55
This group contains parameters that can be used to display a drive parameter in ‘‘User Units.”
Process
Display
[Process Par]
Parameter # 127 Factory Default 1
[Process
Par]
Parameter Type Read & Write Minimum 1
This parameter should be set to the number of the
parameter whose scaled value will be displayed on
Line 1 of the HIM Display Panel when in process mode.
Units Numeric Maximum Max. Parameter Number
[Process Scale]
Parameter # 128 Factory Default +1.00
[Process
Scale]
Parameter Type Read & Write Minimum –327.68
This value sets the scaling multiplier for [Process Par].
The displayed value will be:
[Process Par] actual value
[Process Scale]
value
Displayed Value ➀
Units Numeric Maximum +327.67
[Process Txt 1-8]
Parameter #(s) 129-136 Factory Default ‘‘?’’
[Process
Txt
18]
Parameter Type Read & Write
These parameters set the ‘‘User Units” description for
the value determined by [Process Par] and [Process
Scale]. This text is displayed on Line 1 of the HIM.
Units ASCII Text
Character
➀ The maximum value that can be displayed is 99,999.99. If this value is exceeded a character string of asterisks (
*******
) will appear on the display.
