Programming
5-8
This group of parameters defines the basic operation of the drive and should be programmed before initial
operation. For advanced programming and information on specific parameters, refer to the flow chart on page
5-2 & 5-3
Setup
[In
p
ut Mode]
Parameter # 21 Factory Default “Three Wire”
[Input
Mode]
Parameter Type Read & Write
This parameter selects between Three Wire and Run
Fwd/Rev control. Refer to Chapter 2, Figure 2.7 through
Figure 2.10.
Important: Power must be cycled to the drive for the
change to take effect.
Important:See Frequency Set Group for MOP explanation.
Units Text Setting “Three Wire”
“Run Fwd/Rev”
“3 W/2nd Acc” (2nd Accel)
“Run F/R 2nd A” (2nd Accel)
“3 Wire/MOP”
“Run F/R MOP”
Important:This parameter cannot be
programmed while the drive is running.
[Fre
q
Select 1]
Parameter # 5 Factory Default “Adapter 1”
[Freq
Select
1]
Parameter Type Read & Write Settings ‘‘Remote Pot”
‘‘
0 10 Volt
”
‘‘Preset 1”
‘‘
Preset 2
”
This parameter is the factory default parameter for
selecting the frequency source that will supply the [Freq
Command] to the drive. [Freq Select 2] or [Preset Freq
1–7] can be selected in place of this parameter with proper
terminal block inputs. (See Chart on Page 5-29).
Important: If an adapter that is not connected is selected
as the active frequency source, the drive will fault on “Hz
Sel Fault” (F30).
Units Text
‘‘0-10 Volt”
‘‘4–20 mA”
‘‘MOP”
‘‘Adapter 1”
‘‘Adapter 2”
‘‘Adapter 3”
‘‘Adapter 4”
‘‘Adapter 5”
‘‘Adapter 6”
‘‘Preset 2”
‘‘Preset 3”
‘‘Preset 4”
‘‘Preset 5’’
‘‘Preset 6”
‘‘Preset 7”
