Troubleshooting and Fault Information
6-10
Table 6.C Troubleshooting (continued)
General Problem Action to Take
Motor not accelerating properly. (1) Check motor
- Verify that motor is connected properly.
- Verify that no mechanical problems exist.
2) Check control input signals
- Verify that SW1, SW2, and SW3 are in the proper state to select desired Accel/Decel rates.
(Refer to Table 5.A on page 5-29)
(4) Check parameter settings and charts on Pages 5-29 and 5-30.
- Verify that [Accel Time 1] and [Accel Time 2] are set properly.
- Verify that [Current Limit] is set properly.
- Verify that [DC Boost Select] is set correctly.
- Verify that [Start Boost] and [Run Boost] are set properly.
Specific Problem Action to Take
Can not Jog from Adapter. (1) Verify that [Jog Mask] is set properly to allow jogging from that adapter.
(2) Verify that [Logic Mask] is set properly to allow jogging from that adapter.
(3) Is drive already running?
(4) Examine [Stop Owner] to verify that a maintained Stop does not exist.
Can not change direction from Adapter. (1) Verify that [Direction Mask] is set to allow direction changes from that adapter.
(2) Verify that [Logic Mask] is set to allow direction changes from that adapter.
Can not Start from Adapter. (1) Verify that [Start Mask] is set properly to allow starting from that adapter.
(2) Verify that [Logic Mask] is set properly to allow starting from that adapter.
(3) Is drive already running?
(4) Examine [Stop Owner] to verify that a maintained Stop does not exist.
Display indicates “Not Enabled”. (1) Check enable signal at TB2, terminals 11 & 12.
