Human Interface Module
3-16
CONTROL STATUS MODE (continued)
ACTION
DESCRIPTION
HIM DISPLAY
Fault Queue/
Clear Faults
or
or
or
or
ESC
❏ 2. This menu provides a means to view the fault queue and clear it when
desired.
a. From the Control Status menu, press the Increment (or Decrement) key
until “Fault Queue” is displayed.
b. Press Enter.
c. Press Increment (or Decrement) key until “View Faults” is displayed.
d. Press Enter. The fault queue will be displayed. “Trip” displayed with a
fault will indicate the fault that tripped the drive.
e. Use the Increment (or Decrement) key to scroll through the list.
f. To clear the fault queue, press ESC. Then use the Increment/Decrement
keys to select “Clear Queue”. Press Enter.
Important: Clearing the Fault Queue will not clear an active fault.
Control Status
Fault Queue
Fault Queue
View Faults
Serial Fault
F 10 Trip 1
Fault Queue
Clear Queue
Buffer Number
Location
