Allen-Bradley 1305 Series User Manual

Programming
5-6
Metering Group (continued)
[Out
p
ut Fre
q
]
Parameter # 66 Factory Default None
[Output
Freq]
Parameter Type Read Only Minimum – [Maximum Freq]
This parameter displays the output frequency present at
TB1, terminals T1, T2 & T3 (U, V & W).
Units 0.01 Hz Maximum + [Maximum Freq]
[Fre
q
Command]
Parameter # 65 Factory Default 0.00 Hz
[Freq
Command]
Parameter Type Read Only Minimum 0.00 Hz
This parameter displays the frequency that the drive is
commanded to output. This command may come from any
one of the frequency sources selected by [Freq Select 1],
[Freq Select 2] or [Preset Freq 1-7] the preset speeds 1-7
as determined by the inputs to SW1, SW2, and SW3 at
TB2.
Units 0.01 Hz Maximum +400.00 Hz
[MOP Hz]
Parameter # 42 Factory Default None
[MOP
Hz]
Parameter Type Read Only Minimum 0.00 Hz
This parameter displays the frequency reference
commanded by the Motor Operated Potentiometer (MOP)
function. This MOP frequency command can be adjusted
from TB2-16 and TB2-17 if the appropriate [Input Mode] is
selected. This MOP frequency command can also be
changed through serial communication. This value is
displayed regardless of whether or not this is the active
frequency command.
Units 0.01 Hz Maximum 400.00 Hz
efesotomasyon.com - Allen Bradley,Rockwell,plc,servo,drive

Allen-Bradley 1305 Series Specifications

General

Series	1305
Dimensions	Varies by model
Weight	Varies by model
Frequency Range	50-60 Hz
Control Method	Volts per Hertz
Communication Interface	RS-485
Enclosure Type	IP20
Storage Temperature	-40-70°C
Humidity	5 to 95% non-condensing
