General Specifications
The 1734-AENT adapters have the following general specifications.
General Specifications
Attributes Description
Expansion I/O capacity, max •63 modules
•Up to 5 rack-optimization (for digital modules only) and/or
enhanced rack-optimization (for digital, analog, and specialty
modules) connections
•31 direct connections
(1)
•Backplane current output = 1.0 A.
•Actual number of modules can vary.
•Add together the current requirements for the modules you want
to use to make sure they do not exceed the amperage limit of 1.0 A
for the adapter.
•Backplane current can be extended beyond 1.0 A by 1734-EP24DC
or 1734-EPAC backplane extension power supplies.
•Add multiple 1734-EP24DC or 1734-EPAC modules to reach the 63
module max.
(1) Maximum 31 direct connections for standard I/O or maximum 20 direct connections if any safety I/O module
resides in the backplane.
POINTBus current
requirements, max
•50 mA (Catalog number 1734-IB4D)
•75 mA (Catalog numbers 1734-IB2, 1734-IB4, 1734-IB8, 1734-IV2,
1734-IV4, 1734-OB2, 1734-OB4, 1734-OB8, 1734-OB2E,
1734-OB2EP, 1734-OB4E, 1734-OB8E, 1734-OV2E, 1734-OV4E,
1734-232ASC, 1734-485ASC, 1734-ARM, 1734-IV8, 1734-OV8E,
1734-IE4C, 1734-IE8C, 1734-OE4C, 1734-IA4, 1734-IM4, 1734-OA4,
1734-IR2E, 1734-IE2C, 1734-OE2C, 1734-IE2V, 1734-OE2V,
1734-IA2, 1734-IM2, 1734-OA2)
•80 mA (Catalog number 1734-OW2, 1734-OW4)
•100mA (Catalog numbers 1734-OX2, 1734-8CFG, 1734-4IOL)
•110mA (Catalog number 1734-SSI)
•160mA (Catalog numbers 1734-IJ2, 1734-IK2)
•175mA (Catalog number 1734-IT2I)
•180mA (Catalog numbers 1734-VHSC5, 1734-VHSC24)
•220 mA (Catalog number 1734-IR2, 1734-IR2E)
Module location Starter module – left side of the system.
