Allen-Bradley 1747-ASB Installation Instructions

10 Remote I/O Adapter Module
Publication 1747-IN014C-EN-P - January 2003
Installing the Module
1. Make sure system power is off.
ATTENTION
!
Disconnect power before attempting to install or remove the
module.
1
O N
2456783
SW3
Hold Last State
Processor Restart Lockout
Link Response
Last Chassis/PLC-3 Backup
Addressing Mode Bit 1 (MSB)
Addressing Mode Bit 0 (LSB)
Specialty I/O Mode
I/O Module Keying
Hold Last State
ON Hold Last State
OFF Do not Hold Last State (default)
Processor Restart Lockout
(after lost communications)
ON Automatic Restart (default)
OFF Processor Lockout
Last Chassis
ON Not Last Chassis (default)
OFF Last Chassis
Specialty I/O Mode
ON Discrete (default)
OFF Block Transfer
I/O Module Keying
ON Save Mode (default)
OFF Check Mode
Link Response
ON Restricted (default)
OFF Unrestricted
Addressing Mode
ON ON Invalid
ON OFF 1-slot Addressing (default)
OFF ON 1/2-slot Addressing
OFF OFF 2-slot Addressing
