18 Remote I/O Adapter Module
Publication 1747-IN014C-EN-P - January 2003
Specifications
Adapter Operating Specifications
Baud Rate Determination of Maximum Cable Length and Terminating
Resistor Size
Backplane Current Consumption 375 mA at 5V dc
Operating Temperature 32°F to 140°F
(0°C to 60°C)
Storage Temperature -40°F to +185°F
(-40°C to +85°C)
Humidity 5% to 95% non-condensing
Noise Immunity NEMA standard ICS 2-230
Vibration Displacement: 0.015 inch, peak-to-peak at 5-57 Hz
Acceleration: 2.5Gs at 57-2000 Hz
Shock (operating) 30Gs
Agency Certification
(when product or packaging is marked)
• UL Listed
• CSA certified
• Class I, Division 2 Groups A, B, C, D
• CE compliant for all applicable directives
• Marine Certified
• C-tick marked for all applicable acts
Baud Rate Maximum Cable Distance
(Belden 9463)
Resistor Size
Using Extended
Node Capability
57.6K baud 3048 meters (10,000 feet) 82Ω 1/2 Watt
115.2K baud 1524 meters (5,000 feet)
230.4K baud 762 meters (2,500 feet)
Not Using
Extended Node
Capability
57.6K baud 3048 meters (10,000 feet) 150Ω 1/2 Watt
115.2K baud 1524 meters (5,000 feet)
230.4K baud 762 meters (2,500 feet) 82Ω 1/2 Watt
