Allen-Bradley 1747-ASB Installation Instructions

16 Remote I/O Adapter Module
Publication 1747-IN014C-EN-P - January 2003
Installing Octal Labels
The octal filter and door label kits must be used when working with a PLC
processor as a master. Adhere the octal labels over the existing decimal labels, as
shown below. Contact your local Allen-Bradley distributor if you need to order
additional label kits.
INPUT
1746-XXXX 1746-XXXX (OCTAL)
OCTAL
Decimal Filter Label
Octal Filter Label
Octal Door Label
Decimal Door Label
