Rockwell Automation Publication 1756-UM058G-EN-P - November 2012 201
Tag Definitions Appendix B
Table 49 - 1756-OB16IEF Module Output Data Tags
Name Data
Type
Tag Definition Module Definition
Pt[x].Data BOOL Data—Indicates the On/Off state to apply to the output point.
0 = Off
1 = On
Connection = Data
Output Data = Data or Scheduled
per Module
or
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].ResetFuseBlown BOOL Reset Blown Fuse—Attempts to clear a blown fuse status and apply output data when
the bit transitions from Off to On.
Connection = Data
Output Data = Data or Scheduled
per Module
or
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].OverrideOutputEn BOOL Override Output—Overrides local output data for peer logic with the value defined in
the Pt[x].OverrideOutputValue tag.
0 = Disable
1 = Enable
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].OverrideOutputValue BOOL Override Output Value—Indicates the On/Off status to apply to all outputs mapped to
the output point when the corresponding bit in the Pt[x].OverrideOutputEn tag is set.
0 = Off
1 = On
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].OverridePeerInputEn BOOL Override Peer Input—Overrides peer input data mapped to the output point with the
value defined in the Pt[x].OverridePeerInputValue output tag.
0 = Disable
1 = Enable
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].OverridePeerInputValue BOOL Override Peer Input Value—Indicates the On/Off status to apply to all peer inputs
mapped to the output point when the corresponding bit in the Pt[x].OverridePeerInputEn
output tag is enabled.
0 = Off
1 = On
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].OverridePeerWindow0En BOOL Override Peer Window 0—Overrides peer window 0 inputs mapped to the output point
with the value defined in the Pt[x].OverridePeerWindow0Value output tag.
0 = Disable
1 = Enable
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].OverridePeerWindow0Value BOOL Override Peer Window 0 Value—Indicates the On/Off status to apply to peer window 0
inputs mapped to the output point when the corresponding bit in the
Pt[x].OverridePeerWindow0En output tag is enabled.
0 = Off
1 = On
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].OverridePeerWindow1En BOOL Override Peer Window 1—
Overrides peer window 1 inputs mapped to the output point
with the value defined in the Pt[x].OverridePeerWindow1Value output tag.
0 = Disable
1 = Enable
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].OverridePeerWindow1Value BOOL Override Peer Window 1 Value—Indicates the On/Off status to apply to peer window 1
inputs mapped to the output point when the corresponding bit in the
Pt[x].OverridePeerWindow1En output tag is enabled.
0 = Off
1 = On
Connection = Peer Ownership
Output Data = Data with Peer
Pt[x].PWMCycleTime REAL PWM Cycle Time—Defines the duration of each pulse cycle. Requires PWM to be enabled
via the Pt[x].PWMEnable configuration tag.
Valid values: 0.001…3600.0 seconds
Connection = Data
Output Data = Data or Scheduled
per Module
or
Connection = Peer Ownership
Output Data = Data with Peer
