200 Rockwell Automation Publication 1756-UM058G-EN-P - November 2012
Appendix B Tag Definitions
Pt[x].PeerWindow1OverrideStatus BOOL Peer Window 1 Override Status—Indicates whether peer window 1 data mapped to
the corresponding output point is set up to be overridden by the value in the
Pt[x].OverridePeerWindow1Value output tag. Requires the
O:Pt[x].OverridePeerWindow1En output tag to be enabled.
0 = The override feature for peer window 1 is not enabled.
1 = The override feature for peer window 1 is enabled.
Connection = Peer Ownership
Output Data = Data with Peer
LocalClockOffset DINT Local Clock Timestamp—Indicates the offset between the current CST and the CIP Sync
value when a valid CIP Sync time is available.
Connection = Data
Output Data = Data or Scheduled
per Module
or
Connection = Listen Only
Output Data = None
or
Connection = Peer Ownership
Output Data = Data with Peer
OffsetTimestamp DINT Timestamp Offset—Indicates when the CIP Sync LocalClockOffset and GrandMasterID
were last updated in CIP Sync format.
Connection = Data
Output Data = Data or Scheduled
per Module
or
Connection = Listen Only
Output Data = None
or
Connection = Peer Ownership
Output Data = Data with Peer
GrandMasterClockID DINT Grandmaster Clock ID—Indicates the ID of the CIP Sync Grandmaster to which the
module is synced.
Connection = Data
Output Data = Data or Scheduled
per Module
or
Connection = Listen Only
Output Data = None
or
Connection = Peer Ownership
Output Data = Data with Peer
Timestamp DINT Timestamp—A 64-bit CIP Sync timestamp of the last new output data or FuseBlown
event.
Connection = Data
Output Data = Data or Scheduled
per Module
or
Connection = Listen Only
Output Data = None
or
Connection = Peer Ownership
Output Data = Data with Peer
Table 48 - 1756-OB16IEF Module Input Data Tags (continued)
Name Data Type Tag Definition Module Definition
