110 Rockwell Automation Publication 1791ES-UM001G-EN-P - November 2016
Appendix A Get Diagnostic Status from Modules by Using Explicit Messaging
5. From the top of the Message Configuration dialog box, click Tag.
Figure 42 - Instance 869 Tag Tab
When the explicit message reads the data from the 1791ES-IB16
module, the data appears in the MSGdata tags as shown in Figure 43
.
Figure 43 - Instance 869 MSGdata Tags
