D-2 FLEX I/O HART Modules Network Messaging
Table D.1 Attribute Values
Attribute (Hex) Assembly
Index
Length (Byte) Read/Write Description
HART Common Group
66 7 4 r Extended configuration
67 8 r Calibration
Host Access Group 1
68 9 2 r/w Grant for Group 1 access
69 10 6 r Response Status Information Group 1
6A 11 16 r Status of loops
6B 12 100 r/w Hart request/Response buffer Group 1
6C 13 70 r/w Hart request/Response buffer Group 1
6D 14 56 r/w Hart request/Response buffer Group 1
6E 15 42 r/w Hart request/Response buffer Group 1
6F 16 32 r/w Hart request/Response buffer Group 1
70 17 24 r/w Hart request/Response buffer Group 1
71 18 18 r/w Hart request/Response buffer Group 1
72 19 14 r/w Hart request/Response buffer Group 1
73 20 12 r/w Hart request/Response buffer Group 1
74 21 8 r/w Hart request/Response buffer Group 1
Host Access Group 2
75 22 2 r/w Grant for Group 2 access
76 23 6 r Response Status Information Group 2
77 24 16 r Status of loops
78 25 100 r/w Hart request/Response buffer Group 2
79 26 70 r/w Hart request/Response buffer Group 2
7A 27 56 r/w Hart request/Response buffer Group 2
7B 28 42 r/w Hart request/Response buffer Group 2
7C 29 32 r/w Hart request/Response buffer Group 2
7D 30 24 r/w Hart request/Response buffer Group 2
7E 31 18 r/w Hart request/Response buffer Group 2
7F 32 14 r/w Hart request/Response buffer Group 2
80 33 12 r/w Hart request/Response buffer Group 2
81 34 8 r/w Hart request/Response buffer Group 2
