Configure the 1794-IE8H Module in RSLogix 5000 Software Over the ControlNet Network E-7
Square Root Threshold
Input
Analog Input Data
Underrange Alarm
Bits
[Adapter Name]:[Slot]:C.Data[1].14
[Adapter Name]:[Slot]:C.Data[1].15
15 14 Range
0 0 Disabled
012%
105%
1 1 10%
Channel Words
0 [Adapter Name]:[Slot]:I.Data[0]
1 [Adapter Name]:[Slot]:I.Data[1]
2 [Adapter Name]:[Slot]:I.Data[2]
3 [Adapter Name]:[Slot]:I.Data[3]
4 [Adapter Name]:[Slot]:I.Data[4]
5 [Adapter Name]:[Slot]:I.Data[5]
6 [Adapter Name]:[Slot]:I.Data[6]
7 [Adapter Name]:[Slot]:I.Data[7]
Channel Bits
0 [Adapter Name]:[Slot]:I.Data[8].0
1 [Adapter Name]:[Slot]:I.Data[8].1
2 [Adapter Name]:[Slot]:I.Data[8].2
3 [Adapter Name]:[Slot]:I.Data[8].3
4 [Adapter Name]:[Slot]:I.Data[8].4
5 [Adapter Name]:[Slot]:I.Data[8].5
6 [Adapter Name]:[Slot]:I.Data[8].6
7 [Adapter Name]:[Slot]:I.Data[8].7
