E-8 Configure the 1794-IE8H Module in RSLogix 5000 Software Over the ControlNet Network
Overrange Alarm
Local Fault
Remote Fault
Channel Bits
0 [Adapter Name]:[Slot]:I.Data[8].8
1 [Adapter Name]:[Slot]:I.Data[8].9
2 [Adapter Name]:[Slot]:I.Data[8].10
3 [Adapter Name]:[Slot]:I.Data[8].11
4 [Adapter Name]:[Slot]:I.Data[8].12
5 [Adapter Name]:[Slot]:I.Data[8].13
6 [Adapter Name]:[Slot]:I.Data[8].14
7 [Adapter Name]:[Slot]:I.Data[8].15
Channel Bits
0 [Adapter Name]:[Slot]:I.Data[9].0
1 [Adapter Name]:[Slot]:I.Data[9].1
2 [Adapter Name]:[Slot]:I.Data[9].2
3 [Adapter Name]:[Slot]:I.Data[9].3
4 [Adapter Name]:[Slot]:I.Data[9].4
5 [Adapter Name]:[Slot]:I.Data[9].5
6 [Adapter Name]:[Slot]:I.Data[9].6
7 [Adapter Name]:[Slot]:I.Data[9].7
Channel Bits
0 [Adapter Name]:[Slot]:I.Data[9].8
1 [Adapter Name]:[Slot]:I.Data[9].9
2 [Adapter Name]:[Slot]:I.Data[9].10
3 [Adapter Name]:[Slot]:I.Data[9].11
4 [Adapter Name]:[Slot]:I.Data[9].12
5 [Adapter Name]:[Slot]:I.Data[9].13
6 [Adapter Name]:[Slot]:I.Data[9].14
7 [Adapter Name]:[Slot]:I.Data[9].15
