1 Publication 1794-UM063A-EN-P - March 2006
Chapter
2
Configurable FLEX I/O
Analog Module Features
What This Chapter Contains
Read this chapter to familiarize yourself with configurable features on the
input and output analog modules.
HART configurable features described in this chapter include the following
For Information On See Page
Select Your 1794-IE8H FLEX I/O Analog
Input Module’s Operating Features
2-2
Select Your 1794-OE8H FLEX I/O Analog
Output Module’s Operating Features
2-7
Understand Image Table Mapping and
Bit/Word Descriptions
2-12
Instance: Slot number (range from 1 to 8
with 1 being the I/O module closest to the
adapter
2-19
Table 2.1 Analog/Digital Configurable Features on the FLEX I/O Analog I/O Modules
1794-IE8H Input Module Features 1794-OE8H Output Module Features
Fault Mode Output Enable
Remote Transmitter Error Up or Down Module Fault State Mode
High Low Error Level Local Fault Mode
Input Filter Cutoff Digital Output
Data Format Latch Retry Mode
Global Reset
Analog Digital State
Analog Fault State
Digital Fault State
Data Format
Fault Alarm
