12 PanelView 600 Terminals
41061-004-01(D)
Connecting AC Power
The electrical rating for the PanelView 600 terminal is shown below.
The PanelView 600 terminal is an IEC 1131-2 Equipment Class I device and
requires you to connect the (Protective Earth) terminal to an earth conductor.
To connect AC power to the PanelView 600 terminals:
1. Secure the AC power wires to the L1 and L2N screws on the terminal block.
2. Secure the Earth Ground/Protective Earth wire to the screw on the terminal
block.
Terminal Type Supply Voltage Power Consumption
PV600 85 to 264V ac, 47 to 63 Hz 60 VA maximum
• The PanelView 600 terminal is designed for safe use when
installed in a suitably rated NEMA Type 12, 13, 4X (indoor
use only), IP54 or IP65 enclosure.
• Do not apply power to the terminal until all wiring
connections have been made. Failure to do so may result in
electrical shock.
Explosion Hazard - Do not connect or disconnect equipment
while circuit is live unless area is known to be non-hazardous.
Improper wiring of the power terminals may result in
voltage at the communication connector shells. Refer to the
following figure when wiring.
