84 Configure PhaseManager
PhaseManager Overview
MainTask
Tasks
Water Feed
Other code controls the specific actions of your equipment.
My Equipment Program
Mix Phase
MainProgram
Controller Tags
Controller
Add Water Phase
A PHASE tag gives you the status of an equipment phase.
An equipment phase directs one activity of your equipment.
A state model divides the activity into a series of states.
How to add
water
Running State Routine
Drain Phase
Space Parts Phase
Conveyor Enable Axes
Equipment phase instructions control the transitions between states and
handle faults.
PSC POVR PCLF PRNP PATT
PCMD PFL PXRQ PPD PDET
