Appendix A Specifications
Electrical
Input voltage, DC 24V DC nom (18…32V DC)
Power consumption, DC 70 W max (2.9 A at 24V DC)
39 W typical (1.6A @ 24V DC)
Input voltage, AC 85…264V AC
Line frequency 47…63 Hz
Power consumption, AC 160 VA max, 65 VA typical
External power supply, cat. no. 2711P-RSACDIN
Input voltage, AC
Line frequency
Power consumption, AC
85…264V AC
47…63 Hz
120 VA max
PCI slot, max power DC supply: 5 W
AC supply: 5 W
Weight, approx. for base-configured unit without communication module
700 keypad or keypad/touch
700 touch
1.8 kg (4.1 lb)
1.7 kg (3.7 lb)
1000 keypad or keypad/touch
1000 touch
2.8 kg (6.2 lb)
2.5 kg (5.6 lb)
1250 keypad or keypad/touch
1250 touch
3.4 kg (7.5 lb)
3.2 kg (7.0 lb)
1500 keypad or keypad/touch
1500 touch
4.5 kg (9.9 lb)
4.2 kg (9.2 lb)
Dimensions, approx., (HxWxD) for base-configured unit without communication module
700 keypad or keypad/touch
700 touch
193 x 290 x 55 mm (7.58 x 11.40 x 2.18 in.)
179 x 246 x 55 mm (7.04 x 9.68 x 2.18 in.)
1000 keypad or keypad/touch
1000 touch
248 x 399 x 55 mm (9.77 x 15.72 x 2.18 in.)
248 x 329 x 55 mm (9.77 x 12.97 x 2.18 in.)
1250 keypad or keypad/touch
1250 touch
1250 high-bright touch
282 x 416 x 55 mm (11.12 x 16.36 x 2.18 in.)
282 x 363 x 55 mm (11.12 x 14.30 x 2.18 in.)
282 x 363 x 74 mm (11.12 x 14.30 x 2.90 in.)
1500 keypad or keypad/touch
1500 touch
330 x 469 x 65 mm (12.97 x 18.46 x 2.55 in.)
330 x 416 x 65 mm (12.97 x 16.37 x 2.55 in.)
(1)
Number of function keys varies by terminal size.
Table 68 - Technical Specifications - 2711P-Kxxxx8, 2711P-Txxxx8, 2711P-Bxxxx8,
2711P-Kxxxx9, 2711P-Txxxx9, 2711P-Bxxxx9
Attribute
2711P-Kxxxx8, 2711P-Txxxx8, 2711P-Bxxxx8,
2711P-Kxxxx9, 2711P-Txxxx9, 2711P-Bxxxx9
