62 Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010
Chapter 4 Configuration Mode
Copy Application File or Font File
You can copy Factory Talk View application .mer files or font files from one
storage location to another in the terminal. The procedure for copying an
application file or a font file between storage locations is the same.
1. Select Terminal Settings>File Management>Copy Files>Copy
Applications or Copy Fonts.
2. Press the Source button to choose the location of the file you want to copy.
• Internal Storage - internal flash memory of the terminal
• External Storage 1 - SD card loaded in the card slot of the terminal
• External Storage 2 - USB flash drive connected to a USB host port
3. Select a file from the storage location.
4. Press the Destination button on the same dialog.
5. Press the Destination button to choose the location to copy the file.
The destination must be different than the source location.
6. Press the Copy button to copy the selected file to the destination.
If the file exists, you will be asked if you want to overwrite the file.
7. Select Yes or No.
List of files stored
in flash memory of
terminal.
TIP
FactoryTalk View ME Station software looks for .mer files in the
My Device\Application Data\Rockwell Software\RSViewME\Runtime\
folder and font files in the \Rockwell Software\RSViewME\Fonts\ folder.
