Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010 55
Configuration Mode Chapter 4
Table 33 - Communication Driver Properties
Field Description Valid Values
Serial Properties
Use Auto Config Automatically or manually configures the baud rate, parity, and error
checking parameters.
Yes (auto configure)
No (manual configure)
Device The serial device terminal is connected to. PLC-5, SLC, MicroLogix, Logix
Platform
Error Check Type of error checking used. Error checking is automatically configured if
Use Auto Config is set to Yes.
BCC, CRC
Parity Type of parity used. Parity is automatically configured if Use Auto Config is
set to Yes.
None, Odd, Even
Baud Rate Data rate at which serial driver communicates. The baud rate is
automatically configured if Use Auto Config is set to Yes.
110, 300, 600, 1200, 4800,
9600, 19200, 38400, 57600,
115200
Stop Bits Number of stop bits used. 1 or 2
Ack/Poll Timeout Ack/Poll timeout value in ms. 20…60,000 ms
Max Retries Number of retries before serial driver fails. 0…10
Station Number Station number based on a specific device. 0…254
COM Port Communication port used on the terminal. 1…4
DHPlus Properties
Jumper ID Identifies the communication card if multiple cards are installed on
terminal.
0…3
Station Number The unique address of terminal on the DHPlus network. 0…77 (octal)
Baud Rate The communication rate of the DHPlus network. 57,600 (default)
115,200
230,400
DH-485 Properties
Jumper ID Identifies the communication card if multiple cards are installed on
terminal.
0…3
Station Number The unique station number of the terminal on the DH-485 network. 0…31 (decimal)
Baud Rate The communication rate of the DH-485 network. 9600
19,200
MaxStationNumber The maximum station number on the DH-485 network. The value must be
greater than or equal to the Station Number.
0…31 (decimal)
ControlNet Properties
Device ID Unique address of the PanelView Plus 6 terminal on the ControlNet
network.
1…99
