Rockwell Automation Publication 6000-IN100A-EN-P - August 2020 7
Preface
Commissioning Support After installation, Rockwell Automation is responsible for commissioning
activities for the PowerFlex 6000T product line. Contact your local Rockwell
Automation sales representative to arrange commissioning.
Rockwell Automation support includes, but is not limited to:
• quoting and managing product on-site startups
• quoting and managing field modification projects
• quoting and managing product training at Rockwell Automation
facilities and on-site
Contractor Scope of Work Typical scope of work by the freight company, third-party contractor and/or
customer (based on ex-works INCO terms)
(a)
:
• Load equipment on truck at a Rockwell Automation manufacturing
facility and transport equipment to site
• Offload equipment from truck on-site
• Perform initial inspection
(b)
• Move equipment to the final installation location
• Position the cabinet sections together as shown in Dimensional Drawing
and level the cabinet lineup
• Mechanically join cabinets together
• Affix the cabinets to the floor
• Install assemblies shipped loose (fan assemblies).
• Install external ductwork to exhaust heated air from control room (if
required)
• Install power and control cabling and terminate cable connections to
drive system:
- Connect system ground cable
- Insulation Resistance (IR) testing of incoming line and outgoing
motor power cables
- Connect incoming line and outgoing motor power cables
- Connect control power wiring
- Connect all external customer required control signal wiring
- Connect electrical safety interlock control signal wiring circuit to
input circuit breaker
• Connecting the power cables and control wiring between cabinets that
are shipped separately
(c)
• Complete Pre-commissioning Checklist
(a) All or part of these activities could be provided by Rockwell Automation or its
representatives, based on contract INCO terms and negotiated scope of supply/services
agreement. Contact the local Rockwell Automation office for further information.
(b) Customer should lead the initial inspection process.
(c) Interconnection of power cables and low voltage control wiring bundles, between separately
shipped cabinets, can be done by the contractor or Rockwell Automation. The
commissioning quote from Rockwell Automation reflects this and will contain two options:
a) the base quote, reflecting the power cable and control wiring interconnection work being done by the contractor
b) the optional quote adder, reflecting the additional time and cost for Rockwell Automation to perform the power cable and
control wiring interconnection work immediately before the commissioning process.
