Rockwell Automation Publication 6000-IN100A-EN-P - August 2020 47
Chapter 3
Drive Electrical Interconnection
The drive is shipped in two sections, the Isolation Transformer cabinet and the
Power Module/LV Control cabinet. An optional cabinet may also be supplied.
Drive Mechanical Installation
on page 9 describes mechanically joining these
cabinets together. This chapter describes the activities that are required to
electrically connect these drive cabinets’ components together.
Electrical Interconnection
Summary
Power Cable
Interconnection Overview
Figure 25 provides a three-line drawing overview of the power cable
interconnections between the power modules (PC XX) in the Power Module/
LV Control cabinet and the secondary windings of the isolation transformer in
the Isolation Transformer cabinet. The number of power modules is
dependent solely on output (motor) voltage:
9 power modules for 2.3/2.4/3.0/3.3 kV
12 power modules for 4.0/4.16 kV
15 power modules for 6.0 kV
18 power modules for 6.6/6.9 kV
24 power modules for 10 kV
27 power modules for 11 kV
It also shows the connection point from the U, V, and W motor output phases
from the power module array to the voltage sensing board cables and the
motor cables.
The isolation transformer secondary windings as shown do reflect the actual
orientation on the isolation transformer.
The Power Module/LV Cabinet orientation is optimized for drawing clarity. To
better understand the physical orientation, the components and connections
that are shown in the Power Module/LV Control Cabinet would be rotated 90º
counter clockwise. The U phase is the top horizontal row, the V phase is the
middle horizontal row, and the W phase is the bottom horizontal row.
See the Electrical Drawing (ED) for actual wire number designations.
Connect Internal Cabling and Wiring Page
Connect Isolation Transformer Secondary Power Cables
49
Connect Motor and Voltage Sensing Board Cables 50
Connect LV Control and Fan Wiring Bundles 52
Connect Ground Bus 52
