Allen-Bradley powerflex 700 User Manual

3-66 Programming and Parameters
323, 326 Analog In X Lo Analog Inputs 3-54
324, 327 Analog In X Loss Analog Inputs 3-54
340 Anlg Out Config Analog Outputs 3-54
341 Anlg Out Absolut Analog Outputs 3-54
342, 345 Analog OutX Sel Analog Outputs 3-55
343, 346 Analog OutX Hi Analog Outputs 3-55
344, 347 Analog OutX Lo Analog Outputs 3-55
354, 355 Anlg OutX Scale Analog Outputs 3-56
361-366 Digital InX Sel Digital Inputs 3-57
377, 378 Anlg OutX Setpt Analog Outputs 3-56
379 Dig Out Setpt Digital Outputs 3-58
380,
384, 388
Digital OutX Sel Digital Outputs 3-58
381,
385, 389
Dig OutX Level Digital Outputs 3-58
382,
386, 390
Dig OutX OnTime Digital Outputs 3-59
383,
387, 391
Dig OutX OffTime Digital Outputs 3-59
412 Motor Fdbk Type Speed Feedback 3-20
413 Encoder PPR Speed Feedback 3-20
414 Enc Position Fdbk Speed Feedback 3-20
415 Encoder Speed Speed Feedback 3-20
416 Fdbk Filter Sel Speed Feedback 3-20
419 Notch Filter Freq Speed Feedback 3-20
420 Notch Filter K Speed Feedback 3-21
421 Marker Pulse Speed Feedback 3-21
422 Pulse In Scale Speed Feedback 3-21
423 Encoder Z Chan Speed Feedback 3-21
427, 431 Torque Ref X Sel Torq Attributes 3-18
428, 432 Torque Ref X Hi Torq Attributes 3-18
429, 433 Torque Ref X Lo Torq Attributes 3-18
430 Torq Ref A Div Torq Attributes 3-18
434 Torque Ref B Mult Torq Attributes 3-18
435 Torque Setpoint Torq Attributes 3-19
436 Pos Torque Limit Torq Attributes 3-19
437 Neg Torque Limit Torq Attributes 3-19
438 Torque Setpoint2 Torq Attributes 3-19
440 Control Status Torq Attributes 3-19
441 Mtr Tor Cur Ref Torq Attributes 3-19
445 Ki Speed Loop Speed Regulator 3-29
446 Kp Speed Loop Speed Regulator 3-30
447 Kf Speed Loop Speed Regulator 3-30
449 Speed Desired BW Speed Regulator 3-30
450 Total Inertia Speed Regulator 3-30
451 Speed Loop Meter Speed Regulator 3-30
454 Rev Speed Limit Speed Regulator 3-23
459 PI Deriv Time Process PI 3-29
460 PI Reference Hi Process PI 3-29
461 PI Reference Lo Process PI 3-29
462 PI Feedback Hi Process PI 3-29
463 PI Feedback Lo Process PI 3-29
476-494 ScaleX In Value Scaled Blocks 3-48
477-495 ScaleX In Hi Scaled Blocks 3-48
478-496 ScaleX In Lo Scaled Blocks 3-48
479-497 ScaleX Out Hi Scaled Blocks 3-48
480-498 ScaleX Out Lo Scaled Blocks 3-48
481-499 ScaleX Out Value Scaled Blocks 3-48
600 TorqProve Cnfg Torq Proving 3-59
601 TorqProve Setup Torq Proving 3-59
Number Parameter Name Group Page
602 Spd Dev Band Torq Proving 3-60
603 SpdBand Integrat Torq Proving 3-60
604 Brk Release Time Torq Proving 3-60
605 ZeroSpdFloatTime Torq Proving 3-60
606 Float Tolerance Torq Proving 3-60
607 Brk Set Time Torq Proving 3-60
608 TorqLim SlewRate Torq Proving 3-60
609 BrkSlip Count Torq Proving 3-60
610 Brk Alarm Travel Torq Proving 3-60
611 MicroPos Scale% Torq Proving 3-60
Number Parameter Name Group Page

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
