NetMaster Troubleshooting – KT075 Models Only
54.CE Models Will Not Heat – Electric (continued)
Check for proper
operation of
contactors. Replace
if necessary.
Is there line voltage to
the output side of the
heat contactors?
No
Yes
Correct wiring
between the
elements and
contactors.
Is there line voltage
across the elements?
No
Yes
Check elements for
opens/shorts.
Replace if
necessary.
Do elements produce
heat?
No
Yes
(12)
(11)
Unit operational.
TMB2351S-b
Continued from
previous page
