Troubleshooting
1. Motor Does Not Start
Motor does
not start
Is electrical
power off or
have any fuses
blown?
Check power
and fuses.
Replace fuses
if necessary.
Is loading door
open or is door
switch
inoperative?
No
Close door or
test switch and
replace if
inoperative.
Is lint door
open or is lint
door switch
inoperative?
Close lint door,
confirm switch
is positioned to
actuate with
door closed.
Is
trunnion shaft
assembly
binding in
trunnion housing
bearings?
Replace trunnion
housing bearings.
Is start
circuit
incomplete?
Yes
Yes
Press start switch or
test switch and replace
if inoperative.
Yes
Is idler shaft
binding in idler
housing
bearings?
Replace
bearings.
Yes
Is motor
inoperative?
Have motor tested and
replace if inoperative.
Yes
Non-Metered
Models: Is
timer set
properly?
Turn drying timer clockwise
to desired setting.
Non-Metered
Models: Are the
timer or relay
inoperative?
No
Test timer and relay and
replace if inoperative.
Metered
Models:
Are proper coins
inserted in
accumulator?
If motor still does
not start, replace
motor.
Check that proper
coins are inserted.
Yes
Yes
No
No
No
No
Yes
No
No
Yes
Yes
No
TMB2264S
No
TMB2264S
