Troubleshooting
3. Motor Runs But Cylinder Does Not Turn
Motor runs but
cylinder does
not turn
Is motor
drive
pulley
loose?
Confirm key is
in place,
tighten
setscrews.
Is sheave
loose?
Confirm key is
in place,
tighten
setscrews and
bushing.
Is belt
broken
or loose?
Replace or
adjust belt.
Is
cylinder
binding?
Check cylinder
for binding.
Refer to
Adjustments
Section for
proper cylinder
adjustment.
Does cylinder turn
counterclockwise when
viewed from front of
machine (3 Phase
models only)?
Switch power
leads L1 and
L2 to correct
rotation.
