70422101 49
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Adjustments
Figure 3
TMB2244N
NONREVERSING
Trunnion Housing
Adjusting Bolts
Adjusting
Bolt
Drive V-Belt
Guide Rails
Idler Housing
Assembly
Trunnion
Housing Bolts
Idler Housing
Bolts (2)
Poly V-Belt
(Self-adjusting)
TMB2244N
