Micro Display Control (MDC) Troubleshooting
36.Motor Will Not Start/Run (continued)
Please see following page for wiring diagram information.
Is there supply voltage
across terminals 1 & 4
of motor?
Does the
motor run?
Correct wiring
between
motor and motor
control relay.
Replace
motor.
NO
NO
YES
YES
Motor is
operational.
Note: For high voltage three phase supply
(200 volts or higher), the motor is supplied
by L1, L2, L3 through the motor contactor terminals T1,
T2, T3. Make the appropriate adjustments when
doing voltage checks.
(9)
TMB2306S-b
To Next Page
