Model Gas
Altitude Orifice
New
Rate
feet [m] No.
inches
[mm]
Qua
ntity Part No.
Btu/hr.*
[Mj/hr.]
120L/N Natural Gas 2,001 – 4,000 [610 –
1,220]
18 0.1695 [4.3] 3 M402988 248,400
[262]
4,001 – 6,000 [1,221 –
1,830]
19 0.1660 [4.2] M402995 226,800
[239]
6,001 – 8,000 [1,831 –
2,440]
21 0.1590 [4] M402992 205,200
[216]
8,001 – 10,000 [2,441
– 3,050]
24 0.1520 [3.9] M402980 183,600
[194]
L.P. Gas 2,001 – 4,000 [610 –
1,220]
38 0.1015 [2.6] M411376 248,400
[262]
4,001 – 6,000 [1,221 –
1,830]
40 0.0980 [2.5] M406361 226,800
[239]
6,001 – 8,000 [1,831 –
2,440]
42 0.0935 [2.4] M403017 205,200
[216]
8,001 – 10,000 [2,441
– 3,050]
43 0.0890 [2.3] M406184 183,600
[194]
170L/N Natural Gas 2,001 – 4,000 [610 –
1,220]
16 0.1770 [4.5] 4 M411373 363,400
[383]
4,001 – 6,000 [1,221 –
1,830]
11/64 0.1719 [4.4] 44249901 331,800
[350]
6,001 – 8,000 [1,831 –
2,440]
19 0.1660 [4.2] M402995 300,200
[317]
8,001 – 10,000 [2,441
– 3,050]
22 0.1570 [4] M402996 268,600
[283]
L.P. Gas 2,001 – 4,000 [610 –
1,220 ]
1/8 0.1250 [3.2] 3 M402489 363,400
[383]
4,001 – 6,000 [1,221 –
1,830]
31 0.1200 [3] M401017 331,800
[350]
6,001 – 8,000 [1,831 –
2,440]
32 0.1160 [2.9] M402444 300,200
[317]
8,001 – 10,000 [2,441
– 3,050]
34 0.1110 [2.8] M411512 268,600
[283]
Table 7 continues...
